Our preferred 6" kit for this truck is the 63072 drop down style kit, we like this style due to the great ride that is not commonly found in 2WD lifts. This kit retains both stock upper and lower control arms and ball joints, by using dual lower control arms beams and extended Ductile Iron Steering Knuckles. For Expedition use coil springs, order PT# 753930
|
Ford F150 / Expedition_
2WD Suspension Systems
PT# |
Application |
Lift |
Spindle |
Upper
Arm |
Drop Down
Bracket |
Coils |
Ball
Joints |
Rear
Block Kit |
Shock
Pack |
Price |
63072 |
97’-03’ 1/2 Ton |
6/3 |
63072-2 |
- |
63072-1 |
63072-4 |
- |
63072-5 |
63072-6 |
$1,257.61 |
63071 |
97’-03’ 1/2 Ton |
6/3 |
580335 |
73050 |
- |
663830 |
YES |
F32999 |
YES |
$961.65 |
63070 |
97’-03’ 1/2 Ton |
5/2 |
580330 |
- |
- |
663820 |
- |
F22999 |
YES |
$640.83 |
63069 |
97’-03’ 1/2 Ton |
4/1 |
580330 |
- |
- |
Spacer |
- |
F12999 |
YES |
$520.53 |
63068 |
97’-03’ 1/2 Ton |
3/0 |
580330 |
- |
- |
- |
- |
- |
YES |
$480.42 |
63067 |
97’-03’ 1/2 Ton |
2/0 |
- |
- |
- |
Spacer |
- |
- |
YES |
$213.34 |
63999 |
97‘-03’ Expedition |
6/4 |
63072-2 |
- |
63072-1 |
63072-4 |
- |
753930 |
YES |
$1,400.85 |
63998 |
97‘-03’ Expedition |
5/3 |
580335 |
- |
- |
M03132 |
- |
M02879 |
YES |
$777.90 |
63997 |
97‘-03’ Expedition |
4/2 |
580335 |
- |
- |
M03232 |
- |
M02878 |
YES |
$700.03 |
63093* |
82’-96’ 1/2 Ton |
6/3 |
- |
- |
52180 |
663660 |
- |
YES |
YES |
$894.70 |
63094* |
82’-96’ 1/2 Ton |
4/1 |
- |
- |
52180 |
663640 |
- |
YES |
YES |
$894.70 |
63095 |
82’-96’ 1/2 Ton |
2/0 |
- |
- |
- |
Spacer |
- |
- |
YES |
$287.33 |
* 83’-86’ Requires alignment Cam Bolt kit #25543
* 87’-96’ Requires alignment Cam Bolt kit #25594
 Kit # 63072
Lift Info - Ride Quality (AVERAGE)
This kit contains Extended ductile iron steering knuckles, Dual lower arm beams constructed from 1/4” steel, Extended length 6" lift coils, Rear block & U bolt kit, Front & Rear DT3000 shocks and Extended bump stop. Alignment Cam kit sold separately. PT# 252953
|
 Kit # 63071
6/3 Lift Info - Ride Quality (GOOD)
This kit uses early style upper control arms and 2.5” lift coils along with a 3.5" lift spindle. Rear uses a 3" Block kit, DT3000 shocks included. Alignment Cam kit sold separately. PT# 252953
|
• Specify Cab & Motor size when ordering
• Alignment cam kit sold separately PT# 252953
• Optional 7" Coil-Over kit sold separately allows use of 35" tires - See Coil Over/ByPass
|
