Doetsch 2wd spindles provide between 3" to 4 " of lift by simply replacing your stock spindle. All Doetsch spindles work with your stock upper and lower ball joints and do not require any other special parts. Spindles may be used in conjuction with other suspension parts such as coils, arms, etc. to achieve more lift. All spindles are made from casted ductile iron and heat treated . All Doetsch spindles are made in HAAS CNC Machinery.
|
Chevrolet_
Lift Spindle Applications
PT# |
Application |
Weight |
Style |
Lift |
Footnotes |
Price |
580180 |
00’-10’ Chevy HD |
56lbs |
Cast |
3” |
A,L |
$401.02 |
580170 |
99’-00’ Chevy 2500 |
56lbs |
Cast |
3” |
A,L |
$401.02 |
580199 |
99’-06’ Chevy 1/2 Ton |
40lbs |
Cast |
3” |
A,L |
$401.02 |
580400 |
88’-98’ Chevy 1/2 Ton |
78lbs |
Cast |
4” |
A,L |
$557.00 |
580100 |
88’-98’ Chevy 1/2 Ton |
58lbs |
Cast |
3” |
A,L |
$458.87 |
580120 |
82’-03’ S10 Pickup |
47lbs |
Cast |
3” |
A,B,C,L |
$378.74 |
580130 |
05’-UP Colorado / Canyon |
40lbs |
Cast |
3” |
B,C,L |
$460.62 |
| 582007 |
08'-Up Chevy Silverado 1/2 Ton |
40lbs |
Cast |
3" |
A,L |
$401.02 |
Dodge_
Lift Spindle Applications
PT# |
Application |
Weight |
Style |
Lift |
Footnotes |
Price |
583004 |
02’-04’ Ram 1/2 Ton |
47lbs |
Fab. |
4” |
A,L |
$712.92 |
582021 |
00’-01’ Ram 1/2 Ton |
59lbs |
Cast |
3.5” |
A,L |
$401.02 |
589499 |
94’-99’ Ram 1/2 Ton |
59lbs |
Cast |
3” |
A,L |
$401.02 |
| 583004-2 |
05'-Up Ram 1/2 Ton |
47lbs |
Fab. |
4" |
A,L |
$712.92 |
Ford_
Lift Spindle Applications
PT# |
Application |
Weight |
Style |
Lift |
Footnotes |
Price |
580330 |
97’-6/26/98’ F-150 / Expd. 1/2 Ton |
44lbs |
Cast |
3” |
A,J,L |
$378.74 |
580335 |
6/27/98’-03’ F-150 / Expd. 1/2 Ton |
60lbs |
Cast |
3.5” |
A,K,L |
$401.02 |
589800 |
98’-00’ Ranger only |
47lbs |
Cast |
3” |
A,H,L |
$378.74 |
589810-2 |
01’-09’ Ranger only |
47lbs |
Cast |
3” |
A,H,L |
$378.74 |
589830-10 |
10'-Up Ford Ranger |
|
|
|
|
|
| 589830-2 |
99’-Up Explorer / Edge ( not sport track ) |
47lbs |
Cast |
3” |
A,L |
$378.74 |
Nissan_
Lift Spindle Applications
PT# |
Application |
Weight |
Style |
Lift |
Footnotes |
Price |
585400 |
04”-up Nissan Titan 2WD |
44lbs |
FA |
4” |
L |
$874.00 |
Toyota_
Lift Spindle Applications
PT# |
Application |
Weight |
Style |
Lift |
Footnotes |
Price |
589504 |
95.5”-04” Tacoma (5lug) |
30lbs |
Cast |
3.5” |
A,L |
$333.10 |
Footnotes:
A = Factory wheels will work with some spindles
B = Includes steer stops
C = Requires longer brake line kit #S10BLK (sold separately)
D = Fits “small spud” early regular cab only
G = Includes bearing kit #CK9BC
H = 589800 has 10.25 rotor, 589810 has 11.25 rotor
J = Trucks manufactured from 1997 to 6/26/98 have a large ABS Sensor. Use PT# 580330 the ABS port is large.
K = Trucks manufactured after 6/26/98 can use PT# 580335 (3.5” lift) this spindle has the smaller ABS port.
L = Spindles will not work for racing or pre-running applications.
|
