Listed below are the various combinations that we offer for the Tacoma 2WD, as well as the Tundra 2WD. When ordering kits that include front coil springs you must specify size of Cab and Motor at the time of ordering. For Toyota Tacoma with TRD package, please refer to 4WD Toyota section. (TRD is a 4WD chassis)
|
Toyota_
2WD Suspension Systems
PT# |
Application |
Lift |
Spindle |
Arm |
Coil
Overs |
Block
Kit |
Shackles |
Pack |
Price |
69092 |
00’-06’ Tundra |
3/1 |
- |
- |
X0523 |
T12999 |
- |
REAR |
$1,322.98 |
69088 |
05’-UP Tacoma |
2/0 |
- |
- |
Spacer |
- |
- |
REAR |
$232.83 |
69089 |
05’-UP Tacoma |
3/1 |
- |
- |
X0527 |
- |
62510 |
REAR |
$1,400.85 |
69080 |
95’-04’ Tacoma |
6/3 |
589504 |
75090 |
Coil Over |
- |
62500 |
YES |
$1,478.71 |
69079 |
95’-04’ Tacoma |
6/3 |
589504 |
75090 |
666430 |
- |
62500 |
YES |
$1,050.44 |
69078 |
95’-04’ Tacoma |
5/2 |
589504 |
- |
666420 |
- |
62500 |
YES |
$622.17 |
69077 |
95’-04’ Tacoma |
4/1 |
589504 |
- |
666410 |
- |
62500 |
YES |
$700.03 |
69076 |
95’-04’ Tacoma |
3/0 |
589504 |
- |
- |
- |
- |
YES |
$479.18 |
* 89’-97’ Requires alignment Cam Bolt kit #25594
 Kit # 69092
3/1 Lift Info - Ride Quality (GOOD)
Our 3/1 Coil Over kit bolts directly into your stock mounts using the new (RS) Race Style upper steel coil perch. Your front end can be adjusted from 1” to 3” lift. Kit Includes rear DT3000 Shocks.
|
 Kit # 69079
6/3 Lift Info - Ride Quality (AVERAGE)
This kit contains 3” Spindle, Upper Control Arms, 3” Lift Coils, Rear Shackle,
4 - DT3000 Shocks. Add - A - Leafs sold seperately
|
|
