The Colorado has different choices for the amount of Lift you will need to increase your Tire size. Here are the Lifts we have developed. *Extended Brake Line Kits are necessary on all Spindle Lifts.
Colorado / Canyon_ 2WD Suspension Systems
PT#
Application
Lift
Spindle
Coil Over
Coil or Spacer
Rear Shackle
Shock Pack
Price
61047
04’-06’ Col / Can
5/3
580130
-
665110
720117
YES
$798.93
61046
04’-06’ Col / Can
4/2
580130
-
MD1220
720116
YES
$757.09
61045
04’-06’ Col / Can
3/1
580130
-
-
720116
YES
$705.49
61044
04’-06’ Col / Can
2/0
-
-
MD1220
-
YES
$230.49
X05100
04’-06’ Col / Can
2.5/0
-
X05100
Coil Over Only
-
NO
$777.90
Kit # 61047 5/3 Lift Info
This kit contains a 3” Lift Spindle, 2” Lift Coil and Rear Lift Shackle. Includes Rear Shocks (DT3000)
Kit # 61046 4/2 Lift Info
This kit contains a 3” Lift Spindle, 1” Coil Spacer and Rear Lift Shackle. Includes Rear Shocks (DT3000)
Kit # 61045 3/0 Lift Info
This kit contains a 3” Lift Spindle - Includes Rear Shocks (DT3000)
• Order PT# S10-BLK2 / Extended Brake Line Kits are necessary on all Spindle Lifts
• 3” Spindle Kit uses 17 x 8 Wheel with 5” Backspacing / 285-75R17 Tire
