Ford

Ford SuperDuty F250

Our goal: To achieve enough lift for your 2wd to provide enough room for a 33" to 35" wheel and tire package and retain a smooth stock like ride as much as possible.

Our 6" kit #61073 has hit the mark! Made from dual fabricated lower control arm beams, this in conjunction with a Machined Ductile Spindle allow you to retain your factory upper and lower control arms and ball joints. Kit includes rear impact struts and DT3000 shock absorbers. Shock upgrades to custom and remote reservoir shocks can be made during your purchase. See Tire & Wheel Chart - Must Specify Cab & Motor Size.

Chevrolet_
2WD Suspension Systems

PT#
Application
Lift
Spindle
Upper
Arm
Drop Down
Bracket
Coils
Ball
Joints
Rear
Block Kit
Shock
Pack
Price
61074
99’-06’ Chevy 1/2 Ton
7/4
580194
71020
-
667830
YES
S42999
YES
Discontinued
61073
99’-06’ Chevy 1/2 Ton
6/3
61073-2
-
61073-1
61073-4
-
61073-5
61073-6
$1320.48
61072
99’-06’ Chevy 1/2 Ton
5/2
580199
-
-
2" Spacer
-
S22999
YES
$672.88
61071
99’-06’ Chevy 1/2 Ton
4/1
580199
-
-
Spacer
-
S12999
YES
$546.55
61070
99’-06’ Chevy 1/2 Ton
3/0
580199
-
-
-
-
-
YES
$504.45
61069
99’-06’ Chevy 1/2 Ton
2/0
-
-
-
667820
-
-
YES
$251.80

• See HD Chevy 2wd

Kit # 61074
7/4 Lift Info - Ride Quality (AVERAGE)

This kit consists of upper arms with bump stops, 3" coil springs and a 4" fabricated lift spindle. Rear comes with a 4" block kit and front and rear DT3000 shocks. * May require ball joint alignment spacer kit #25000 (Included)


Kit # 61073
6/3 Lift Info - Ride Quality (GOOD)

Made from dual fabricated lower control arm beams, this in conjuction with a Machined Ductile Spindle allow you to retain your factory upper and lower control arms and ball joints. Kit includes rear impact struts and DT3000 shocks.




Kit # 61071
4/1 Lift Info - Ride Quality (GOOD)

This kit includes our 3" lift spindle and an upper urethane coil spacer. Rear is a 1" block kit and front & rear DT3000 shocks. Note: Shock upgrades can be done at the time of purchase to any kits.
